Model 3030 Monitors for Industrial and Military Applications.
Features:
- 30" diagonal LCD
- WQXGA 2560x1600 Native Resolution
- Rugged design intended for harsh environments
- Metal Enclosure with VESA mount, Rack mount, Console mount or Tabletop
- Optional Bonded Glass
- VESA DPMS compliant, VESA DDC1/2 plug and play compliant
- Dual Link DVI-D connector
General Information
-=Very High Resolution=-
EDL Displays Color Monitors have the highest resolution available. The .29mm dot pitch liquid crystal display provides the sharpest images available with resolutions up to and including 2560 X 1600.
-=Fast Response Time=-
With a video response time of 14msec the 3030 can display full motion video.
-=Reliability=-
The monitor is designed with reliability as paramount in importance. Reliability is accomplished by using high quality parts and assuring that these parts are operating at less than their intended stress levels.
-=Ease of Adjustment=-
All controls that may be necessary to adjust in the field are available via the on screen display menu.
Specifications
-=Display=-
Active Area: 641.28mm x 400.8mm (25.2" x 15.78")
Native Resolution: 2560 X 1600
Pixel Pitch: 0.250mm (0.0833 X RGB)
Colors: 16,777,216 (256 gray levels)
Contrast Ratio: 700:1 (typical, at 25°C)
Luminance: 400 cd/m²
Luminance Variation: 25% (MAX, AT 25°C)
Viewing Angle, H: ±89° (typical, for CR ≥ 10)
Viewing Angle, V: ±89° (typical, for CR ≥ 10)
CIE White: X = 0.313, Y = 0.331 (typical at 25°C)
Response Time: 12msec (G to G), 14msec (B to B) (typical, at 25°C)
-=Backlight=-
Type: CCFL
Lifetime: 50,000 hrs (typical, at 25°C)
-=Electromagnetic Environment=-
Susceptibility: Per EN50082-1
Emissions: Per EN50081-1, FCC class B
-=Safety=-
Safety: Per UL/C 1950, EN60950
-=Physical Environment=-
Temperature (operating): 0°C to +50°C
Temperature (storage): -20°C to +60°C
Relative Humidity (operating): 90%, non-condensing (to 50°C)
Relative Humidity (storage): 90%, non-condensing (to 55°C)
Altitude (operating): Sea level to 15,000ft (4500m)
Altitude (storage): Sea level to 40,000ft (12000m)
Shock (operating): 30g, 11msec ½ sine
Shock (storage): TBD
Vibration (operating): ±1mm, 2 to 13Hz; 0.7g, 13 to 100Hz, 3 axes
Vibration (storage): TBD
Weight (in standard configuration): 36lbs. (16.3Kg)
Power (in standard configuration): 95W
-=Inputs=-
Signal Connector: Dual Link DVI-D
